MAD Suspension Air Master Light FORD Galaxy CK

Kit Number: NR-067096
Engine: Incl. Hybrid
Year: 01/2015 to present day
Height Difference (mm):
Install Time (min): 60
Approval: TUV
Remarks:

MAD SEMI AIR SUSPENSION

Auxiliary air springs are used in combination with the original vehicle suspension. It provides support in a maximum range. From empty to loaded. Always the desired comfort, stability and safety under all circumstances.

Improve driveability, comfort and road safety. Semi air suspension systems by MAD provide additional and adjustable support to the vehicle's original suspension system. The ride height is controllable with semi air suspension, making it ideal for use in various loading situations. MAD provide a wide product range of air suspension systems making it possible to choose the right system to suit both the requirements of the driver and the vehicle.

Air Master Light

A simple solution to keep the vehicle at height with cargo. You put the red air bags into the original rear coil springs. Ideal for vehicles that are occasionally loaded. The ride height is not affected when empty. A smart and compact semi air bag system for passenger cars and small vans.

The Air Suspension Master Light is the ideal solution when the vehicle:
• is alternately loaded
• stands too low when loaded
• is unstable or sways when loaded
• sags
• bottoms out or hits the end stops

Advantages Air Suspension Master Light:
+ Prevents sagging (static)
+ Prevents hitting the end stops of suspension system
+ Prevents bottoming out (tow bar/rear on thresholds)
+ Optimum traction with front-wheel drive
+ Ideal driving characteristics in all loading situations
+ Prevents swaying of trailer or caravan
+ Reduces damage to the undercarriage
+ Contributes to safety

Optional Compressor Kit One

With this add on kit for Air Master Light it provides more convenience. This kit ensures that the air springs always maintain the minimum pressure. In addition, you can read the pressure and manually fill or relieve the air springs via the paddle switch. The kit includes a universal control panel, compressor and mounting materials.
