MAD Suspension Air Master Premium MERCEDES-BENZ Sprinter 910

Kit Number: NR-097044-CE
Engine: All
Year: 02/2018 to present day
Height Difference (mm):
Install Time (min): 180
Approval: TUV
Remarks: Only Chassis Cabine. Only FWD. Incl. LED Headlights. Only wide axle (code AH1)

MAD SEMI AIR SUSPENSION

Auxiliary air springs are used in combination with the original vehicle suspension. It provides support in a maximum range. From empty to loaded. Always the desired comfort, stability and safety under all circumstances.

Improve driveability, comfort and road safety. Semi air suspension systems by MAD provide additional and adjustable support to the vehicle's original suspension system. The ride height is controllable with semi air suspension, making it ideal for use in various loading situations. MAD provide a wide product range of air suspension systems making it possible to choose the right system to suit both the requirements of the driver and the vehicle.

Air Master Premium

A powerful and flexible semi air suspension system for vehicles with leaf springs, always giving the right support under any load condition. The air springs are installed on or next to the original suspension system, for light commercial vehicles, motorhomes and special vehicles. This kit supports the original suspension with air bellows, improving driving characteristics, stability, and safety of the vehicle. The ride height is adjustable, making it ideal for use in various loading situations.

A perfectly tuned semi air suspension system
• Developed and tested for each vehicle to ensure optimal quality, driving characteristics and safety.
• Pre-assembled for quick and easy installation.
• MAD air suspension systems are TÜV certified.
• MAD systems comply with directive ECE R13.
• High Quality Product – Made in the Netherlands (EU).
• Reliability - MAD Air Springs come with 2 year warranty.

PREMIUM – With compressor and digital handheld controller

The Premium set is equipped with the new controller. Thanks to the intuitive operation with LED display, you can easily adjust the ride height on the left and right independently. The ideal choice for light commercial vehicles and motorhomes with varying or heavy loads.

Benefits of the Premium set:
+ The controller can be placed anywhere in the cabin – install it wherever suits you best.
+ Intuitive operation and independent control (left/right)
+ No air lines behind the dashboard – faster, neater and clearer.
+ No CAN-bus connection – no impact on vehicle systems.
+ Plug & play installation with the Connection Hub – all connectors at one central point.

Kit Contents
• 2 air springs
• Compressor
• Connection Hub
• Valve Block
• Controller
• Mounting materials
• Approval document
• Installation manual

Code in article number -CE Controller
