Fits Vehicle:
Toyota Hilux Mk.8-9 2016+ / 2021+ Hilux
Model KUN125L / KUN126L.
Kit Number: HV-364570
Engine: All
Year: 05-2015 to
Height Difference (mm):
Install Time (min): 45
Approval: TUV
Spring Compressors: No
Remarks:
Specification:
Pair of power coil springs for Rear
Spring Type - Auxiliary Spring (helper spring) working with original set-up
Fitting time 45 Mins
MAD High Quality Product
Reliability - MAD products come with lifelong warranties
Quick installation, without excessive work
Specially developed for each individual car model
Convenient, no adjustments of original springs
Saves on maintenance and repair costs
MAD AUXILIARY SPRINGS
Auxiliary springs are fitted in or next to the existing main spring. They only come into action when the load reaches a certain load level. In other words, when the main spring is no longer capable of handling the increased load. The auxiliary spring provides the required extra capacity when this happens.
A spring that works in this way is referred to as a progressive spring. Auxiliary springs are easy to fit in most cases.
Coil springs can be easily fitted or replaced by a garage in nearly all cases. MAD's coil springs are high-quality components and approved by TUV and RDW. This means that they meet the highest international automotive standards. So MAD offers a lifetime warranty on the auxiliary springs.
[tab name='Downloads']
PDF Flyer: MAD Toyota Hilux Springs | |
Install Guide: Mad Suspension Auxiliary Coil Spring Toyota Hilux | |
Warranty Policy: MAD Suspension Systems |
