Fits Vehicle:
Mercedes X-Class Double Cab 2017+
(with rear coil spring suspension)
Kit Number: NR-317086
Engine: All
Year: 09-2017 to
Height Difference (mm):
Install Time (min): 90
Approval: TUV
Spring Compressors: No
Remarks: Excl. vehicles with raised chassis
Specification:
MAD High Quality Product
Advantage that original springs remain active
Quick installation, without excessive work
Red Air Bag kit which is mounted inside original coil spring
Air Bag supports original coil suspension
Max pressure approx. 3,5 bar (approx 60 psi.)
To protect the bellows a minimal pressure sensor is included as standard
Also safety valve that expels air when the pressure is to high (3,7 bar)
The force of two together can be adjusted with the air pressure
Easy to operate, Variable setting depending on load
Production in accordance with ISO and TÜV requirements
MAD AUXILIARY AIR SUSPENSION
If you want to be comfortable on the road in both loaded and unloaded situations. More comfort, stability and safety with a MAD air suspension system.
An alternative to auxiliary suspension by means of a coil spring is auxiliary air suspension. MAD has two types of auxiliary air suspension - An air bag that is placed inside the coil spring or air bellows that are mounted next to the original spring.
Depending on the existing suspension of your vehicle, one of the two auxiliary air suspension applications is possible. If the existing suspension is insufficient due to, for example, an extra heavy load, the auxiliary suspension is activated.
MAD AIR MASTER LIGHT - Auxiliary air suspension red bag mounted in original coil spring.
MAD AIR MASTER BASIC - Auxiliary air suspension black bellows with 2 manual filling valves.
MAD AIR MASTER COMFORT - Auxiliary air suspension bellows with compressor and operation panel.
